VG1-63REW-A1 油泵詳解

VG1-63REW-A1 是高壓內嚙合定量齒輪泵，屬于伺服級低脈動、低噪聲泵型，主打中高壓、高效率、長壽命，適配伺服節能液壓系統。

一、型號編碼規則

• VG1：系列代號，內嚙合齒輪泵（伺服型）
• 63：幾何排量 63 mL/r
• R：轉向，右旋（軸端看順時針）
• E：密封材質，丁腈橡膠（NBR）
• W：油口位置，側進側出
• A1：安裝形式，標準 SAE 法蘭 + 平鍵軸

二、結構組成（內嚙合核心）

• 泵體：高強度鑄鐵，剛性強、散熱好、抗沖擊
• 主動齒輪（外齒）：合金鋼淬火，齒面耐磨
• 內齒圈（從動）：合金鑄鐵，內齒廓精密研磨
• 月牙板（主 / 副）：浮動式，徑向間隙自動補償
• 浮動側板：雙側壓力補償，軸向間隙動態補償
• 泵軸：高硬度合金鋼，平鍵驅動、徑向力平衡
• 軸承：高精度滑動軸承，低摩擦、耐高速
• 密封：NBR（-20℃～+80℃），可選 FKM 高溫密封

三、工作原理

1. 內嚙合吸壓油：主動齒輪帶動內齒圈同向旋轉，齒槽容積變化完成吸油→壓油；無困油現象，流量連續平穩。
2. 雙補償機制：軸向：浮動側板隨壓力變形，補償磨損間隙，維持高容積效率徑向：浮動月牙板自動貼合齒輪，減少內泄、提升低壓性能
3. 低脈動輸出：特殊齒廓 + 多齒同時嚙合，流量脈動 \\<±1 bar\\，噪聲低（≤65 dB）。

四、核心參數（標準工況）

• 幾何排量：63 mL/r
• 額定壓力：210 bar（21 MPa）
• 峰值壓力：250 bar（25 MPa）
• 最高轉速：3000 rpm（推薦 1200–2000 rpm）
• 容積效率：≥94%（150 bar、1500 rpm）
• 總效率：≥88%（額定工況）
• 噪聲：≤65 dB(A)（150 bar、1500 rpm）
• 介質粘度：10–860 cSt（推薦 32–68 cSt 抗磨液壓油）
• 工作溫度：?20℃～+80℃（FKM 可達 + 120℃）
• 重量：≈32 kg

五、性能優勢

1. 超低脈動 + 低噪：內嚙合設計 + 雙補償，脈動遠低于葉片泵 / 外嚙合齒輪泵，適合伺服精密系統。
2. 高效耐久：雙補償 + 耐磨齒面，內泄小、發熱低、壽命長（可達 10,000 小時）。
3. 寬工況適配：600–3000 rpm 穩定運行，低速 / 低粘度下仍保持高效率。
4. 抗污染強：齒輪副間隙大 + 自清潔設計，對油液污染不敏感，適應惡劣工況。
5. 結構緊湊：內嚙合體積小、重量輕，安裝空間小，可串聯成雙聯泵。

六、典型應用

• 注塑機 / 壓鑄機：伺服節能系統、精密控制、低噪需求
• 工程機械：中高壓液壓系統、重載工況、長壽命要求
• 冶金 / 機床：高壓動力源、多執行器、低脈動控制
• 叉車 / 物流設備：高效節能、低噪、寬轉速范圍

七、使用注意

1. 油液清潔：建議10 μm過濾，延長泵芯壽命
2. 轉速控制：避免長期 <600 rpm 或> 2500 rpm，防止效率下降或過熱
3. 壓力匹配：長期工作壓力建議≤180 bar，延長壽命
